LaserPecker LP5 - The Smart 20W Fiber + Diode Laser Engraver
$2,899.00USD
$3,299.00
Save $400.00
- The most capable, lightest weight, and most compact engraver in its class. Versatile and reliable on a wide range of materials, for multiple application scenarios.
- Engrave at up to 10,000mm/s, rapid engraving task completion, batch processing with variable text and smart filling.
- Deep engraving for high-contrast markings, vivid 3D grayscale embossing, ultra-precise metal cutting.
- Safely engrave and deliver instant services indoors, for retail stores, maker spaces and creative studios.
Notice: Color of free cutting plate varies from different batches.
Package
LP5 Standard Bundle
$3,299.00 $2,899.00
LP5 Business Bundle
$3,999.00 $3,359.00
LP5 All-in-One Bundle
$4,399.00 $3,699.00
LP5 Safety Bundle
$3,999.00 $3,799.00
LP5 Portable Bundle
$3,299.00 $3,038.00
Frequently Bought Together
$ $
Quantity
Buy Now
Fast Shipping, for more information, please refer to our Shipping Policy
7-day Price Guarantee
24-hour Customer Service
Safe & Secure Checkout
LP5 Standard Bundle
The Smart 20W
Dual Laser Engraver
Industry's smallest 2-in-1 laser engraver with 20W fiber and 20W diode laser sources,
versatile for engraving on almost all materials.
20W Fiber Laser
Stainless steel, aluminum, brass, silver, plastic, platinum, titanium, gold, and so on.
20W Diode Laser
Wood, acrylic, leather, glass, rock, paper, rubber, food, and so on.
More Powerful
Engraving Abilities
Deep Engraving
Achieve greater depth in a single path with clean, well-defined edges, and exceptional details.
3D Grayscale Embossing
Experience LaserPecker's software expertise and precision control for captivating grayscale engravings on wood, rocks, and metals.
View How to Turn Photo into 3D Embossed >Rediscover the joy of color engraving
Rather than limiting oneself to monochrome designs, the journey of experimenting with color engraving can inspire your craftsmanship.
View How to Color Engrave Your Favorites >
Precision Cutting for Optimal Results
Precise control over cutting angles and geometry, surpassing traditional lasers, cuts up to 1mm of brass, stainless steel, aluminum, and titanium sheets.
Craft You Masterpiece
Powerhouse in Portability
The LP5 is the most capable, lightest weight, and most compact engraver in its class, and its ease of portability makes it an ideal companion for versatile and on-the-go customization.
Handheld Engraving
With LP5, the possibilities for your projects are no longer limited by location or access to a stationary setup. Whether working on-site, in your workshop, or even outdoors, this compact and portable laser engraver allows you to create in the places that inspire you most.
Versatile Engraver for Every Scenario
Instant In-Store Customization
Craftsman's Pursuit of Exceptional Design
Workshop Achieving Professional Engraving
Instant In-Store Customization
Craftsman's Pursuit of Exceptional Design
Workshop Achieving Professional Engraving
Your Pathway to Superior Engraving Mastery
Speed for
Unmatched Efficiency
The LP5 is a speed beast, capable of engraving at up to 10,000mm/s, providing precise and rapid results akin to industrial-grade machines.
With
Slide Extension
Effortlessly manage high-volume production during peak periods of urgency with the Slide Extension, enhancing both efficiency and speed.
With
Rotary Extension
Personalize cylindrical objects like tumblers, mug cups, glasses, bracelets, and rings with precision using the Rotary Extension.
Batch Processing
Has Never Been Easier
The Power of
Variable Text
Say goodbye to manual adjustments. Variable Text streamlines batch production, effortlessly engraving elements like serial numbers, dates, or personalized messages into designs.
Plug. Tap. Engrave.
Step 1: Plug in USB Drive
Step 2: Select Project and Preview
Step 3: Engraving Done
When Safety
Matters Most
Rigorously tested and certified, the LP5
enclosure system fully complies with EU
regulations.
Both the conical protective cover and safety enclosure are equipped with door sensors that instantly halt laser operation when opened
Safeguarded Engraving By Design
Redundant safety mechanisms deliver comprehensive control
and ensure your engraving workspace stays secure.
Overheat
Protection
Emergency
Stop Button
Access-Control
Security Key
Smart and Efficient Engraving
Camera for
Smart Filling
Simplify your engraving workflow with our integrated camera feature. Housed within a safety enclosure, the camera helps you pinpoint the perfect position and automatically fills your materials when you align them uniformly. Let the function handle the details, ensuring enhanced accuracy and efficiency.
A Blending of Functionality
and Convenience
Engraving Ecosystem Empowers Seamless Workflow
Powerful yet intuitive PC software and mobile app - LaserPecker Design Space, give you complete command over the engraving jobs for an easy, efficient experience.
Proof Before You Groove
Achieve perfect engraving with the dual red dots focusing and direct safe preview options.
See LaserPecker LP5 in Action
Fresh Start Customs
11.4K subscribers
This is a super cool machine it's going to be really great for Mobile kiosks or fairs, for sure like I said already this is going to be um the go-to for using on your mobile handheld
EBPMAN Tech Reviews
187K subscribers
LaserPecker LP5 because one of the things that makes this engraver stand out, the fact that it has a very powerful fiber laser, you're going to see how fast it's able to engrave and how clean it's able to engrave.
Vintauri
21.8K subscribers
The LP5 shines with 20W fiber + blue diode power in an unbeatably compact design—way more portable than clunky alternatives with separate controllers. Even fully kitted, it’s easy to take on-site. Love the upgraded removable shroud: easy to use, blocks light from all angles, and keeps on-location jobs safe.
More
Accessories
Shop for more machine upgrade solutions
How-To Guides for LP5
Turn Any Photo into 3D Embossed Art with LaserPecker LP5
Laser Engraving in COLOR?! LP5 & LP4 Just Changed the Game
Packing List
Specifications
| Type | Details |
|---|---|
| Dimension | Laser Unit: 255 x 98 x 183mm Electric Stand: 198 x 286 x 323mm Conical Protective Cover: 167 x 231 x 160mm |
| Net Weight | Laser Unit: 3.36 kg Electric Stand: 2.28 kg Conical Protective Cover: 0.38 kg Total Weight: 6.02 kg |
| Laser Power & Laser Source | 20W 450nm Blue Diode Laser 20W 1064nm Fiber Laser |
| Working Area | 120 x 160mm (Ellipse) 100 x 100mm (Square) 160 x 300mm (With the Slide Extension) |
| Laser Spot Size | 0.08 x 0.1 mm (20W Diode Laser) 0.06 x 0.06 mm (20W Fiber Laser) |
| Max. Working Speed | 10000mm/s |
| Engraving Precision | 0.0027mm |
| Preview Mode | Rectangle Preview/Outline Preview/Center Point Preview |
| Supported File Formats | PC Software: G-code/JPG/PNG/BMP/SVG/DXF etc.
Mobile App: G-code/JPG/PNG/SVG |
| Connectivity | USB, Wi-Fi |
| Supported OS | Support iOS 9.0+, Android 7.0+, macOS 10+, Windows 10+ Compatible with LightBurn |
| Safety Certification | CE/ROHS/FCC/FDA/NCC/KC/UKCA/TELEC/SRRC |
| Type |
|---|
| Dimension: |
| Laser Unit: 255 x 98 x 183mm
Electric Stand: 198 x 286 x 323mm Conical Protective Cover: 167 x 231 x 160mm |
| Net Weight: |
| Laser Unit: 3.36 kg
Electric Stand: 2.28 kg Conical Protective Cover: 0.38 kg Total Weight: 6.02 kg |
| Laser Power & Laser Source: |
| 20W 450nm Blue Diode Laser
20W 1064nm Fiber Laser |
| Working Area: |
| 120 x 160mm (Ellipse)
100 x 100mm (Square) 160 x 300mm (With the Slide Extension) |
| Laser Spot Size: |
| 0.08 x 0.1 mm (20W Diode Laser)
0.06 x 0.06 mm (20W Fiber Laser) |
| Max. Working Speed: |
| 10000mm/s |
| Engraving Precision: |
| 0.0027mm |
| Preview Mode: |
| Rectangle Preview/Outline Preview/Center Point Preview |
| Supported File Formats: |
| PC Software: G-code/JPG/PNG/BMP/SVG/DXF etc. Mobile App: G-code/JPG/PNG/SVG |
| Connectivity： |
| USB, Wi-Fi |
| Supported OS: |
| Support iOS 9.0+, Android 7.0+, macOS 10+, Windows 10+ Compatible with LightBurn |
| Safety Certification: |
| CE/ROHS/FCC/FDA/NCC/KC/UKCA/TELEC/SRRC |
Specifications
General Information
| Type | Details |
|---|---|
| Product Size | Laser Unit: 255 x 98 x 183mm Electric Stand: 198 x 286 x 323mm Conical Protective Cover: 167 x 231 x 160mm |
| Product Weight | Laser Unit: 3.36 kg Electric Stand: 2.28 kg Conical Protective Cover: 0.38 kg Total Weight: 6.02 kg |
| Laser Type | 20W 450nm Blue Diode Laser +20W 1064nm Fiber Laser |
| Supported Materials | 20W 1064nm Fiber Laser:
Stainless Steel, Aluminum, Brass, Silver, Plastic, Platinum, Titanium 20W 450nm Blue Diode Laser: Wood, Acrylic, Leather, Glass, Rock, Paper, Rubber |
| Working Area | 120 x 160mm (Ellipse) 160 x 300mm (with the Slide Extension) |
| Max. Working Speed | 10000mm/s |
| Cutting Depth | Up to 1mm of Brass, Stainless Steel, Aluminum, and Titanium sheets Up to 15mm thick Black Acrylic Up to 20mm Basswood |
| Max. Processing Height | 137mm |
| Max. Rotary Engraving Diameter | 200 mm |
Smart Software
| Type | Details |
|---|---|
| Supported Software | LaserPecker Design Space App & PC Software & LightBurn |
| Operating System | Mobile - iOS 13.0+ & Android 7.0+
PC - macOS 10.15+ & Windows 10+ |
| Connection Method | USB, Wi-Fi |
| Supported Files | PC Software: G-code/JPG/PNG/BMP/SVG/DXF etc. Mobile App: G-code/JPG/PNG/BMP/SVG |
| Preview Method | Rectangle Preview/Outline Preview/Center Point Preview |
Accuracy & Precision
| Type | Details |
|---|---|
| Laser Spot Size | 0.08 x 0.1 mm (20W Diode Laser) 0.06 x 0.06 mm (20W Fiber Laser) |
| Positioning Precision | 0.0027mm |
| Image Resolution | 1K/2K/4K/8K |
| Motion Accuracy | 0.0027mm |
General Information
| Type | Details |
|---|---|
| Safety Certification | CE/ROHS/FCC/FDA/NCC/KC/UKCA/TELEC/SRRC |
| Input Power | DC(24V⎓7.5A) 180W
AC(100-240V,50-60Hz) |
| Supported Language | English, German, Spanish, French, Japanese, Korean, Polish, Russian, Portuguese, Simplified Chinese and Traditional Chinese |
Specifications
General Information
| Product Size |
|---|
| Laser Unit: 255 x 98 x 183mm
Electric Stand: 198 x 286 x 323mm Conical Protective Cover: 167 x 231 x 160mm |
| Product Weight |
| Laser Unit: 3.36 kg
Electric Stand: 2.28 kg Conical Protective Cover: 0.38 kg Total Weight: 6.02 kg |
| Laser Type |
| 20W 450nm Blue Diode Laser
+20W 1064nm Fiber Laser |
| Supported Materials |
| 20W 1064nm Fiber Laser: Stainless Steel, Aluminum, Brass, Silver, Plastic, Platinum, Titanium 20W 450nm Blue Diode Laser: Wood, Acrylic, Leather, Glass, Rock, Paper, Rubber |
| Working Area |
| 120 x 160 mm (Ellipse)
160 x 300 mm (with the Slide Extension) |
| Max. Working Speed |
| 10000 mm/s |
| Cutting Depth |
| Up to 1mm of Brass, Stainless Steel, Aluminum, and Titanium sheets
Up to 15mm thick Black Acrylic Up to 20mm Basswood |
| Max. Processing Height |
| 137mm |
| Max. Rotary Engraving Diameter |
| 200 mm |
Smart Software
| Supported Software |
|---|
| LaserPecker Design Space App & PC Software & LightBurn |
| Operating System |
| Mobile - iOS 13.0+ & Android 7.0+ PC - macOS 10.15+ & Windows 10+ |
| Connection Method |
| USB, Wi-Fi |
| Supported Files |
| PC Software: G-code/JPG/PNG /BMP/SVG/DXF etc. Mobile App: G-code/JPG/PNG /BMP/SVG |
| Preview Method |
| Rectangle Preview/Outline Preview/Center Point Preview |
Accuracy & Precision
| Laser Spot Size |
|---|
| 0.08 x 0.1 mm (20W Diode Laser)
0.06 x 0.06 mm (20W Fiber Laser) |
| Positioning Precision |
| 0.0027mm |
| Image Resolution |
| 1K/2K/4K/8K |
| Motion Accuracy |
| 0.0027mm |
General Information
| Safety Certification |
|---|
| CE/ROHS/FCC/FDA/NCC/KC /UKCA/TELEC/SRRC |
| Input Power |
| DC(24V⎓7.5A) 180W
AC(100-240V,50-60Hz) |
| Supported Language |
| English, German, Spanish, French, Japanese, Korean, Polish, Russian, Portuguese, Simplified Chinese and Traditional Chinese |
